Corporate Case
S332
S332-01
S332-02
S332-03
Model Number: S332
| Front Panel: | ABS with Airflow Hole | |
| Left Side / Top Panel: | Steel | |
| Right Side Panel: | Steel | |
| Chassis: | SGCC 0.6mm | |
| Front I/O: |
USB2.0 x 4 (without USB 3.0 or Type-C) USB3.0 x up to 2 (optional, each use a USB2.0 slot) |
|
| PSU Position/Type: | Back (and Top if stood up) / TFX PSU | |
| PSU: |
TFX series 200W to 300W (Nomal Efficiency) TFX series 200W to 300W (APFC, 80+ PLUS Bronze version) |
|
| Motherboard Type: | Micro ATX (Max 244*244mm), Mini ITX | |
| Reserved Fan Ports: (optional) | Front: 1 x 80mm Black 3-Pin Fan or: 1 x 80mm PWM Fan |
|
| Rear: None | ||
| Top: None | ||
| Side: None | ||
| Bottom: None | ||
| Drive Bays: | Slim ODD（9.5mm) x 1 (Tool-less design) | |
| 3.5” exposed x 0 | ||
| 3.5” HDD x 1 (Tool-less design) | ||
| 2.5” SSD x 1 (Tool-less design) | ||
| PCI Expansion Slots: | 4 x Half Height / Low Profile Slots | |
| Chassis Size: |
327 x 95 x 266mm（8.3L）W/O Front Panel 327 x 95 x 283mm（8.8L）With Front Panel |
|
| Max.VGA Card: | Up to 220mm | |
| Max. CPU Cooler: | Up to 50 mm | |
| Security/Internal SPK (Optional): |
Padlock Loop / Kensington Slot (Included) Chassis Intrusion Switch / Internal Speaker (Optional) |
|
About Meredian
Meredian is located in Causeway Bay, Hong Kong. The factory special in computer chassis, power supply and computer peripheral equipment design, manufacture. Established to offer DIY Pc builders great hardware and design our team works hard on R&D to keep offering update designs that you will love. Products are exported all over Asia and Europe through sales channels built up over many many years in the industry. We work with our customers to give them ideal product in quantities right for them.
