UPS – Uninterruptible Power Supply
UPS-RACK-2000VA
UPS-RACK-2000VA-01
UPS-RACK-2000VA-02
UPS-RACK-2000VA-03
Model Number: RACK 2000VA
| Power: | 1600W | |
| Rack Height: | 3U | |
| Noise: | <50db (1 metre) | |
| Temperature: | 0 – 40°C | |
| Humidity: | 10% – 90% | |
| Input – Phase: | Single & GND | |
| Input – Voltage Range: | 220 ~ 240VAC | |
| Input Frequency: | 50 Hz / 60 Hz ± 10% (Auto-Sense) | |
| Output – Voltage Range: | 220 ~ 240VAC | |
| Output – Wave Form: | Pure Sine Wave | |
| Output Frequency: | 50 / 60Hz ± 0.3Hz (Auto-Sense & Selectable) | |
| Output – Efficiency: | Max 98% (AC mode) Max 85% (Linear Load) | |
| Output Transfer Time: | 8ms | |
| Protection Overload (AC Mode): | 110% For 120s, 125% For 60s, 150% For 10s (Transfer To Bypass Mode) | |
| Protection Overload (Inverter Mode): | 110% For 60s, 125% For 10s, 150% For 5s (Shut Down Directly) | |
| Protection LAN: | RJ45 Surge Protection (Two sockets one in one out for pass through) | |
| Noise Filtering EMI / RFI: | Full time suppression | |
| Communication: | USB (SNMP – Optional) | |
| Output Sockets: | 2 x Mains Sockets | |
| Output Sockets: | 3 x IEC 320 C13 Sockets | |
| USB Port: | One (For USB Monitoring) | |
| Battery – Type: | Sealed Lead-Acid Maintenance Free Battery | |
| Battery – Qty: | 12V9AH x 3 | |
| Battery – Recharge Time: | 90% Capacity After 8 Hours | |
| Battery – Backup Time: | 10-30 minutes (Dependent On Load) | |
| Unit Dimensions (mm): | 440mm x 132mm x 415mm (W x H x D) | |
| Net Weight (KGs): | 21.3 KGs | |
| Gross Weight (KGs): | 24.8 KGs | |
