Corporate Case
6811
6811-01
6811-02
6811-03
Model Number: 6811 (24L)
| Front Panel: | Plastic | |
| Left Side Panel: | Metal TAC2.0 Vented | |
| Right Side Panel: | Metal | |
| Chassis: | SGCC 0.5mm Metal | |
| Front I/O | SD/TF Card Reader Included (Built-in) USB3.0 x 1 USB2.0 x 3 HD Audio Microphone |
|
| PSU Position/Type | Top / ATX PSU | |
| Motherboard Type | Micro ATX, Mini ITX | |
| Reserved Fan Ports: (optional) | Top: None | |
| Rear: 1 x 80mm / 92mm Fan | ||
| Front: 1 x 80mm / 92mm Fan | ||
| Side: TAC2.0 Vented | ||
| Drive Bays: | 5.25” exposed x 1 | |
| 3.5” exposed x 0 | ||
| 3.5” HDD x 3 | ||
| 2.5” SSD x 1 | ||
| PCI Expansion Slots: | 4 x Full Size | |
| Chassis Size: | L415*W173*H370 MM (Including Fascia / Panels) | |
| N.W.; | 4.1KGS | |
| G.W.: | 4.9KGS | |
| Max.VGA Card: | 350mm | |
| Max. CPU Cooler: | 145mm | |
| Water cooling:(optional) | Not Water Cooling Ready | |
| Cable Management: | 21 mm | |
About Meredian
Meredian is located in Causeway Bay, Hong Kong. The factory special in computer chassis, power supply and computer peripheral equipment design, manufacture. Established to offer DIY Pc builders great hardware and design our team works hard on R&D to keep offering update designs that you will love. Products are exported all over Asia and Europe through sales channels built up over many many years in the industry. We work with our customers to give them ideal product in quantities right for them.
